CE SF6 33KV GIS High Voltage Switchgear for Power Generation

Name: CE SF6 33KV GIS High Voltage Switchgear for Power Generation
Brand: Bosun
Price: 999 USD

Wholesale CE SF6 33KV GIS High Voltage Switchgear for Power Generation from china suppliers

Brand Name : Bosun

Certification : ISO9001, CE, CQC,CCC

Place of Origin : Chongqing

MOQ : 1

Price : 999 - 9999 USD

Payment Terms : T/T, L/C, Western Union

Supply Ability : 2000 PCS per Month

Delivery Time : 15 Working Days

Packaging Details : Wooden case

Product name : SF6 Insulated High Voltage Switchgear

ODM/OEM : Accepted

Color : As required

Certificate : ISO,9001 CQC,CCC,CE

Payment : T/T L/C

Packing : Wooden Case

Contact Now

33KV CE Certificates SF6 Insulated High Voltage Switchgear for Power Generation

Product Description

33KV CE Certificates SF6 Insulated High Voltage Switchgear for Power Generation is specifically designed for use with renewable energy sources like wind and solar power, which are gaining popularity due to their environmental sustainability benefits.
The switchgear enables parallel operation of multiple generators or renewable energy sources, which enhances efficiency and reliability by distributing the load across multiple sources.
This pad-mounted switchgear is installed at ground level, easily accessible for maintenance and service, and has a small footprint, making it suitable for use in areas with limited space.
It has an IP65 ingress protection rating, which means it is highly resistant to dust and water, and can withstand harsh environmental conditions, making it perfect for outdoor applications.
With voltage levels ranging from 3 kV to 36 kV, the switchgear is designed to operate in high voltage applications, making it suitable for a wide range of renewable energy projects including wind farms, solar power plants, and other renewable energy systems.
Depending on the specific application requirements, the switchgear may use various types of circuit breakers, such as vacuum circuit breakers or SF6 gas circuit breakers, providing greater flexibility in design and operation.
The switchgear may meet various international standards, such as IEC and ANSI, ensuring it meets the highest quality and safety standards, making it reliable and safe for the project.
The switchgear may be customized to fulfill specific customer requirements, such as remote monitoring and control, automation, and communication capabilities. This flexibility in operation and management can help to enhance the efficiency and reliability of the renewable energy system.

Main Technical Parameters

Main Technical Parameters	Specifications
Rated voltage	40.5KV
Rated frequency	50Hz
Rated current of the main busbar	1250A, 1600A, 2000A
Rated insulation level 1min power frequency withstand voltage	95KV between phases and relative, 115KV for the first isolating joint
Lightning impulse withstand voltage	185KV between phases and relative, 215KV for the first isolating joint
1min power frequency withstand voltage of the auxiliary control circuit	2KV
Dimensions (widthdepthheight)	14002800(3000)2800
Rated current of branch busbar	630A, 1250A, 1600A

Marketing

CE SF6 33KV GIS High Voltage Switchgear for Power Generation

Our business scope covers 6 continents and over 50 countries.

Delivery and Payment

Design
